MTU 471 Engine Diesel Generator

MTU 471 Engine

The MTU 471 engine, also known as the Mercedes-Benz OM 471, is a six-cylinder in-line diesel engine that is part of the BlueEfficiency Power series. This engine is designed for commercial vehicle applications and is known for its high performance, fuel efficiency, and compliance with stringent emission standards. The OM 471 is characterized by its soft and quiet engine running, achieved primarily through high-pressure common rail direct injection. It offers a high level of mechanical smoothness due to its excellent mass balance and is equipped with advanced electronic control systems for optimal performance. The engine is also designed to meet various emission standards, including EU 5, EEV, and EU 6, making it a versatile choice for a wide range of applications.

Xuzhou Shunming Construction Machinery Co., Ltd. Was established in 2019. It is a comprehensive enterprise integrating new and old construction machinery procurement, maintenance and preparation, sales, warehousing, transportation, machinery operation and financial services. Our main products are Concrete Pump Truck,Concrete Mixer Truck,Dump Truck,Truck Crane,Wheel Loader and so on.

Product Parameters Table for MTU 471 Engine

Specification	Details
Engine Type	Six-cylinder in-line diesel engine
Displacement (cm³)	12809
Bore × Stroke (mm)	132 × 145
Valve Train	2 overhead camshafts (DOHC)
Compression Ratio	17.0:1
Cooling	Water cooling
Fuel	Diesel min. 51CZ
Fuel Preparation	Common rail - direct injection
Emission Standard	EU 5, EEV, EU 6
Charging	Turbocharger with asymmetrical air supply or Turbocompound Technik
Application Area	Commercial Vehicle Engine, built-in engine
Range of Services	240–460 kW (326–625 PS)
Torque	1100–1400 Nm at 1200–1600 min⁻¹
Fuel Processing Specialty	Common-Rail (max. 2500 bar), variable valve timing
