Used Volvo EC380 Excavator

Volvo EC380 Excavator

The Volvo EC380 excavator is a powerful and efficient machine designed to enhance your operational profitability. This heavy-duty crawler excavator combines higher productivity with improved fuel efficiency, allowing you to achieve more with less. With its new generation of smart electro-hydraulic systems that provide flow on demand and reduce internal losses in the hydraulic circuit, the EC380 offers outstanding fuel efficiency. The ECO mode further aids in achieving excellent fuel economy. The hybrid version of the EC380, utilizing Volvo's unique hydraulic hybrid technology, charges accumulators during the boom downswing and uses the stored energy to power an auxiliary motor, providing additional power to the engine system, resulting in a fuel efficiency increase of up to 20% while maintaining all the power and performance you expect from the traditional EC380 model. The EC380 is equipped with Dig Assist, which supports the machine's work efficiency through a 10-inch Volvo Co-Pilot display, offering a suite of smart applications including 2D, on-site design, 3D software packages, and on-board weighing, all aimed at optimizing the digging process. With its impressive performance, fuel efficiency, and operator comfort, the Volvo EC380 is a reliable choice for various construction and excavation tasks.

Product Parameters Table for Volvo EC380 Excavator

Specification	Details
Model	EC380
Engine Model	Volvo D13F
Rated Power (kW/rpm)	245/1800
Net Power (ISO 9249/SAE J1349) (kW)	236
Gross Power (ISO 14396/SAE J1995) (kW)	245
Maximum Torque (Nm)	1720
Engine Speed at Max Torque (rpm)	1350
Rotation System	Max Rotation Speed (rpm): 10.2
Max Rotation Torque (kNm)	130.5
Travel System	Max Traction Force (kN): 276.5
Max Travel Speed (High/Low) (km/h)	5.1/3.3
Climbing Ability (°)	35
Hydraulic System	Main Pump Max Flow (L/min): 2×317
溢流阀设定	Executing Hydraulic Circuit (MPa): 32.4
Travel Circuit (MPa)	35.3
Rotation Circuit (MPa)	27.9
Fuel Tank (L)	620
Hydraulic System Total (L)	500
Hydraulic Tank (L)	225
Engine Oil (L)	55
Engine Coolant (L)	60
Operating Weight (kg)	37800-41100
BUCKET CAPACITY (ISO Full Bucket) (m³)	1.7-1.9
Arm Length (mm)	6450
Boom Length (mm)	6450
Dipper Stick Length (mm)	3200
Track Shoe Width (mm)	600
Max Digging Force (kN)	243
Max Dumping Height (mm)	7450
Max Reach at Maximum Digging Depth (mm)	11070
